AT-FS970M Switch Command Line User’s Guide
1699
MATCH PROTOCOL
Syntax
match eth-format layer-two-format protocol layer-three-
protocol
Parameters
eth-format
Indicates the following parameter is a Layer 2 Ethernet format.
layer-two-format
Specifies the Layer 2 Ethernet format. For a list of entries, see
Table 234.
protocol
Indicates the following parameter is a Layer 3 protocol.
layer-three-protocol
Specifies the Layer 2 Ethernet protocol. For a list of entries, see
Table 235 on page 1700.
Mode
Class Map mode
Description
Use this command to set one Ethernet format and one protocol as a
matching criteria for a class map. You can also assign one Ethernet format
or one protocol to a class map with this command.
See “NO MATCH PROTOCOL” on page 1726 for information about how to
remove an Ethernet format and protocol from a class map.
Table 234. Layer Two Ethernet Formats
Parameter Description
802dot2-tagged Indicates 802.2 tagged packets.
802dot2-untagged Indicates 802.2 untagged packets.
ethii-tagged Indicates Ethii tagged packets.
ethii-untagged Indicates Ethii untagged packets.
netwareraw-tagged Indicates NetWare Raw tagged packets.
netwareraw-untagged Indicates NetWare Raw untagged packets.
