Chapter 100: QoS Storm Control Protection
1772
Shutting Down a
Port
The following example sets the storm protection action to shut down the
port assigned to the policy map named “pmap1.” See Table 244.
awplus(config-pmap)# class
cmap1 Associates an existing class map, called
“cmap1,” to policy map “pmap2” and
enters the Policy Map Class mode.
awplus(config-pmap-c)# storm-
protection Enables the QSP feature.
awplus(config-pmap-c)# storm-
action portdisable Sets the storm action to disable a port.
Table 243. Setting Storm Control Action: Disabling a Port (Continued)
Command Description
Table 244. Setting Storm Control Action: Shutting Down a Port
Command Description
awplus> enable Enters the Privileged Executive mode
from the User Executive mode.
awplus# configure terminal Enters the Global Configuration mode.
awplus(config)# mls qos enable Activates the QoS feature on the switch.
awplus(config)# policy-map
pmap1 Creates a policy map called “pmap1” and
enters the Policy Map mode.
awplus(config-pmap)# class
cmap1 Associates an existing class map, called
“cmap1,” to policy map “pmap1” and
enters the Policy Map Class mode.
awplus(config-pmap-c)# storm-
protection Enables the QSP feature.
awplus(config-pmap-c)# storm-
action linkdown Sets the storm action to shut down a
port.
