AT-FS970M Switch Command Line User’s Guide
1669
Displaying QoS
Status
To display the status of the QoS feature, use the SHOW MLS QOS
command at the Global Configuration mode. The command syntax is:
show mls qos
See Figure 253 for an example of this command when QoS is disabled.
For more information about this command, see “SHOW MLS QOS” on
page 1667.
Figure 253. SHOW MLS QOS Command
Displaying a
Class Map
To display the contents of a class map, use the SHOW CLASS-MAP
command in the Privileged Exec mode. Here is the command syntax
followed by an example display:
awplus# show class-map cmap2
See Figure 254 for an example of this command.
Figure 254. SHOW CLASS-MAP Command
Displays the mappings of CoS priority
values to egress queues of a specified
port. show mls qos maps cos-queue
Displays the mappings of DSCP values
to egress queues of a specified port. show mls qos maps dscp-queue
Displays the mapping between the
existing DSCP value and the new
DSCP value. show mls qos maps policed-dscp <0-63>
Table 230. QoS Display Commands (Continued)
To Do This Task Use This Command
Qos is disabled
CLASS-MAP-NAME: cmap2
Set IP DSCP: 56
Match IP DSCP: 7
