AT-FS970M Switch Command Line User’s Guide
1805
IPv4 decimal masks 16 and 24 are equivalent to masks 255.255.0.0 and
255.255.255.0, respectively.
There are four local networks in the example, and each network must have
its own routing interface. Here are the commands for creating the routing
interfaces:
At this point, the switch begins to route IPv4 packets among the four local
networks.
awplus# configure terminal Enter the Global Configuration
mode.
awplus(config)# interface vlan4 Enter the VLAN Interface mode for
the Sales VLAN with the ID 4.
awplus(config-if)# ip address 149.35.67.11/24 Create the IP routing interface
149.35.67.11 in the Sales VLAN.
awplus(config-if)# interface vlan5 Enter the VLAN Interface mode for
the Production VLAN with the ID 5.
awplus(config-if)# ip address 149.35.68.24/24 Create the IP routing interface
149.35.68.24 in the Production
VLAN.
awplus(config-if)# interface vlan11 Enter the VLAN Interface mode for
the Engineering VLAN with the ID
11.
awplus(config-if)# ip address 149.35.69.23/24 Create the IP routing interface
149.35.69.23 in the Engineering
VLAN.
awplus(config-if)# interface vlan15 Enter the VLAN Interface mode for
the Inventory VLAN with the ID 15.
awplus(config-if)# ip address 149.35.70.45/24 Create the IP routing interface
149.35.70.45 in the Inventory
VLAN.
awplus(config-if)# end Return to the Privileged Exec
mode.
awplus# show ip interface Confirm the new routing
interfaces.
