AT-FS970M Switch Command Line User’s Guide
1755
Figure 271. SHOW MLS QOS MAPS DSCP-QUEUE Command
The mappings of DSCP value and egress queues are set with “MLS QOS
MAP DSCP-QUEUE” on page 1718.
DSCP-TO-QUEUE-MAP:
---------------------
Queue: 0
DSCP: 0-7
---------------------
---------------------
Queue: 1
DSCP: 8-15
---------------------
---------------------
Queue: 2
DSCP: 16-23
---------------------
---------------------
Queue: 3
DSCP: 24-31
---------------------
---------------------
Queue: 4
DSCP: 32-39
---------------------
---------------------
Queue: 5
DSCP: 40-47
---------------------
---------------------
Queue: 6
DSCP: 48-55
---------------------
---------------------
Queue: 7
DSCP: 56-63
---------------------
