CIM_IPRoute table
Description Data Type Column Name
LUID uniquely defining this table row BIGINT IPRoute_LUID
Partly identifies CIM_IPRoute BIGINT NodeID
Partly identifies CIM_IPRoute BIGINT SnapshotID
Equates to CIM_IPRoute NVARCHAR(256) CreationClassName
For future use NVARCHAR(256) ServiceCreationClassName
For future use NVARCHAR(256) ServiceName
Equates to CIM_ComputerSystem NVARCHAR(256) SystemCreationClassName
The value of CIM_ComputerSystem.Name with equal
NodeID NVARCHAR(256) SystemName
NVARCHAR(256) IPDestinationAddress
The IP address that serves as the destination of the traffic,
formatted according to the appropriate convention as
defined in the AddressType property of this class (This
property has the same semantics as DestinationAddress
inherited from the NextHopRouting superclass but uses a
different property name because this property and class
were defined before NextHopRouting and are Key
properties. They cannot be removed. ModelCorrespondence
indicates that they should be set to equivalent values for
consistency and ease of searching.) NVARCHAR(256) IPDestinationMask
An enumeration that describes the format of the address
property (Addresses that can be formatted in IPv4 format
must be formatted that way to ensure mixed IPv4/IPv6
support. AddressType is part of the key so that an IPv4 and
an IPv6 route to IP subnets with the same network number
but different versions (v4/v6) can coexist. (0, Unknown; 2,
IPv4; 2 IPv6)) SMALLINT AddressType
True indicates that this is a static route and False indicates
a dynamically-learned route bit IsStatic
Contains the address of the next-hop router or the interface
used to reach the destination NVARCHAR(256) NextHop
Not standard and is the gateway to the route destination
(Unknown, Local, Remote) NVARCHAR(32)
Not standard and is the argument list for the
/usr/sbin/route
command
NVARCHAR(1024) dc_RouteArgument
CIM_iSCSICapabilities table
Description Data Type Column Name
LUID uniquely defining this table row BIGINT ISCSICapabilities _LUID
Used to partially identify CIM_iSCSICapabilities BIGINT NodeID
Used to partially identify CIM_iSCSICapabilities BIGINT SnapshotID
Used for reporting purposes NVARCHAR(255) Elementname
Used for reporting purposes NVARCHAR(255) InstanceID
Used for reporting purposes BIT MinimumSpecificationVersionS
Used for reporting purposes BIT MaximumSpecificationVersionS
