HP 288048 User Manual
Automatic airless spray guns, Instructions - parts
![background image](/manuals/98169/1/background.png)
311053C
Instructions - Parts
Automatic Airless
Spray Guns
Part No. 288048
For airless spraying of paints and coatings.
Part No. 288554
For sealant streaming applications.
4000 psi (28 MPa, 280 bar) Maximum Working Fluid Pressure
Mounting manifolds must be ordered separately. Refer to Parts section.
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
TI8089a
Model 288048 Shown
II 2 G c T6
