Configuring enhanced beacons and probes
6
1. Select Security > Enhanced Probe/Beacon Table from the main menu tree.
2. Select the Beacons Found tab.
3. Refer to the following information as displayed within the Beacons Found tab.
4. Select the Clear Report button to clear the statistic counters and begin a new data calculation.
Reviewing found probes
Refer to the Probes Found tab to view the enhanced Probe report created by the switch. The table
displays probe information collected during the AP’s channel scan. The information displayed
within the Probes Found tab is read-only with no user configurable parameters.
To view the enhanced beacons table report:
Portal MAC Displays the MAC address of the unadopted AP detected by the enhanced beacon
supported AP.
Rogue AP MAC Displays the MAC address of the enhanced beacon supported AP.
Signal Strength (dBm) Displays the signal strength when the unadopted AP was detected.
Heard Channel Displays the channel frequency when the unadopted AP was detected.
Heard Time Displays the time when the unadopted AP was detected.
