252 Brocade Mobility RFS7000-GR Controller System Reference Guide
53-1001944-01
DHCP server settings
5
1. Select Services > DHCP Server from the main menu tree.
2. Select the Dynamic Bindings tab.
3. Refer to the contents of the Dynamic Bindings tab for the following:
4. Select an address from those displayed and click the Delete button to remove the client from
the list displayed. The Delete button is enabled only when one or more rows are selected for
deletion.
5. Click on Delete All Automatic Leases button to delete all the automatic leased DHCP
connections. This button is enabled when one or more rows exist.
6. Click the Export button to display a screen used to export the DHCP Binding information to a
secure location.
Configuring the DHCP user class
The DHCP server assigns IP addresses to clients based on user class option names. Clients with a
defined set of user class option names are identified by their user class name.
IP Address Displays the IP address for each client whose MAC Address is listed in the MAC
Address / Client ID column. This column is read-only and cannot be modified.
MAC Address / Client
ID Displays the MAC address (client hardware ID) of the client using the switch’s
DHCP Server to access switch resources. The MAC address is read-only and cannot
be modified.
Expiration Displays the expiration of the lease used by the client for switch DHCP resources.
This column is read-only and cannot be modified.
