Chapter 4: Meridian Link/CCR hardware 79
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
Power supply
The slide-in power supply (shown in Figure 25) is available in two versions:
¥
NT7D64AA for AC-powered systems
¥
NT7D64DC for DC-powered systems
The power supply converts incoming 220 V AC, or Ð48 V DC, to +5 V and
±12 V DC voltages, then distributes these voltages throughout the
Application Module.
Figure 25
Power supply (Application Module)
