208 Chapter 9: Meridian Link/CCR interface cabling
553-3202-210 Standard October 1998
NT8D37 backplane cable rerouting for segment 3Ñto
accommodate the IPE Module in PE slots 12Ð15
With the cables located as shown in Table 67:
1
Leave cable R as is in slot position L12.
2
Remove cable T from the backplane and connect cable ends T-1,
T-2, and T-3 to slot positions L15-1, L15-2, and L15-3.
3
Move the T connector on the I/O panel to position U. Now the cable
designation is changed from T to U.
!
CAUTION
Risk of hardware damage
With this cable rerouting, the IPE Module can be used
only in PE slots 12Ð15. Also, when the IPE Module is not
in PE slots 12Ð15, PE slot 14 should not be used at all.
Note: Reroute the cable only in the segment where the IPE Module is
going to be installed. Do not reroute the cable in other segments.
