Chapter 9: Meridian Link/CCR interface cabling 239
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
Figure 67
Application Module MVME712A, MVME705B, NT6D51AA cablingÑI/O subpanel (CCR)
SP1, Console
SP2, TTY
SP3
SP4
Teledapt
Printer
NT7D79AA
NT7D46AA
Customer-supplied
(or NT7D61 cable)
to system console
DB9
DB9
DB9
Undefined port
NT7D61 to SDI
(NT7D46 to SDI Paddle Board)
Not used with AM
SP5
SP3
DB25
SP1
DB25
NT7D58 to ESDI or MSDL
J2
NT7D46AA
MVME712A Transition card
MVME705B Transition card
¥
Customer-supplied cable to
external modem
SP3
SP2
DB25
SP1
DB25 J4
NT6D51AA Transition card
DB25
NT7D48AA
NT7D48AA
NT7D95AA
NT7D95AA
NT7D95AA
J5
J6
NT8D96AE
NT8D96AE
NT8D96AE
J3
A (Port 4)
B (Port 5)
C (Port 6) To terminals
and/or
printers
A (Port 7)
B (Port 8)
(Not used)
I/O sub-panel
Application Module
A (Port 1)
B (Port 2)
C (Port 3)
(INTERNAL CABLING)
(EXTERNAL CABLING)
J7
J8
J9
