Chapter 9: Meridian Link/CCR interface cabling 199
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
NT8D37 backplane cable expansionÑsegment 3
1 Leave cable R in slot position L12.
2 Move cable end S-3 from slot position L14-1 to slot position L13-3.
3 Remove cable T from the backplane and connect cable ends T-1,
T-2, and T-3 to slot positions L14-1, L14-2, and L14-3.
4 Add cable U to the I/O panel by connecting cable ends U-1, U-2, and
U-3 to slot positions L15-1, L15-2, L15-3.
The IPE shelf is now ready to receive an IPE Module in slots 12Ð15.
Table 68 lists cable connections for a fully expanded configuration.
Figure 53 shows the backplane slots in a fully expanded configuration.
