Chapter 14: Software installation, upgrade, and update procedures 415
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
Procedure 5: Load the operating system tape on an Application Module
with an MVME147 card (continued)
Figure 146
Disk/tape controller list after aligning LUNs
Disk Controllers Available
LUN Type Address # dev
0 VME147 $FFFE4000 1 SCSI Addr = 0 - FUJITSU M2614S M606
1 VME147 $FFFE4000 1 SCSI Addr = 1
2 VME147 $FFFE4000 1 SCSI Addr = 2
3 VME147 $FFFE4000 1 SCSI Addr = 3
4 VME147 $FFFE4000 1 SCSI Addr = 4 - TEAC MT-2ST/N50 RV F
5 VME147 $FFFE4000 1 SCSI Addr = 5
6 VME147 $FFFE4000 1 SCSI Addr = 6
VME147 $FFFE4000 * SCSI Addr = 7
Save map in NVRAM [Y,N] N?
8 The LUN results appear (Figure 146). Type y and press [Return] to
save the map in non-volatile memory.
9 The 147-Diag> prompt reappears. Type ab and press [Return] to set
autoboot enable.
Autoboot enable prompts appear. Answer them as indicated below.
Figure 147
Autoboot enable prompts
Controller LUN = 00?
Device LUN = 00?
Default String = ?
Boot at Power-up only or any board Reset [P,R] = R?
On any board Reset:
Auto Boot from Controller 0, Device 0
10 At the Ò147-Diag>Ó prompt, type reset and press [Return].
The SCSI bus reset prompts appear. Answer them as indicated in
the following figure.
