Chapter 9: Meridian Link/CCR interface cabling 231
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
Figure 59
I/O subpanel connectors (Meridian Link)
J9 J8 J7
J6 J5 J4
J3 J2 J1
Meridian Link I/O subpanel
¥ ¥
¥ ¥ ¥
Host
connection
(Link 1)
External
modem SDI
port Console
Meridian 1 connection
(Link 0) ¥
Meridian Mail connection
(Link 2)
J9 J8 J7
J6 J5 J4
J3 J2 J1
¥ ¥
¥ ¥ ¥
¥
¥
