60 Chapter 4: Meridian Link/CCR hardware
553-3202-210 Standard October 1998
!
CAUTION
Risk of data loss
Do not press both the
ABORT
and the
RESET
switches at
the same timeÑyou risk losing device configuration
information.
The MVME712 transition card makes all serial I/O connections for the SBC
card. The SBC card communicates with the transition card through the
P2/J2 connector and the P2 adapter board. The SBC card connects to the
VME bus through the P1/J1 connector for address and data signals.
