Meridian America Link/Customer Controlled Routing - Manual (Page 477)

Chapter 14: Software installation, upgrade, and update procedures 459
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
Procedure 8: Load the application software from tape (continued)
Figure 226
Software management menu
SOFTWARE MANAGEMENT
1 installpkg install new software package onto built-in disk
2 listpkg list packages already installed
3 removepkg remove previously installed package from built-in disk
Enter a number, a name, the initial part of a name, or
? or ? for HELP, q to QUIT:
5 At the software management menu, type 1 and press [Return] to
select the install option.
Figure 227
Drive selection menu
Select which drive to use:
1 ctape 2 diskette1 3 hddiskette1
Enter a number, a name, the initial part of a name, or
? for HELP, q to QUIT:
6 You are prompted to select a drive. Type 1 and press [Return] to
select the ctape (cassette tape) option.
Figure 228
Insert medium prompt
Insert the removable medium for the package you want to install
into the ctape drive.
Press when ready. Type q to quit.
7 You are prompted to insert the medium. Insert the application tape
(tape 2 of 2) into the tape drive and wait until the tape indicator light
turns off.
Once the tape is inserted correctly and the latch is completely
closed, the tape indicator light goes on, flashes briefly, then goes off
again. Wait until the light goes off before proceeding to the next step.
