Chapter 9: Meridian Link/CCR interface cabling 173
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
ESDI/MSDL cabling (Options 21Ð81 IPE Module)
As shown in Figure 45, port 5 of the NT1R03AA cable connects to the
NT6D80 MSDL card through an NTND27AB cable and, if additional
length is needed, through an NT1R03D extension cable. For pinouts of the
NT1R03AA, NT8D82, NT1R03D, and NTND27 cables, refer to ÒExternal
I/O cable pinoutsÓ in this chapter. From the Meridian 1 I/O panel or the
ESDI/MSDL on the Meridian 1, an NT7D58 cable connects to the IPE
Module. Refer to Table 55.
As shown in Figures 45 and 46, port 5 of the NT1R03AA cable connects to
the QPC513 ESDI card through an NT8D82 cable and, if additional length
is needed, through an NT1R03D extension cable. The NT6D80 MSDL card
connects to the Meridian 1 I/O panel using an NTND27 SCSI II cable. From
the Meridian 1 I/O panel or the ESDI/MSDL on the Meridian 1, an NT7D58
cable connects to the IPE Module at
¥ J2 on the I/O subpanel
¥ ESDI Link port on the universal I/O panel
¥ card 2 conn 1 on the generic I/O panel
SDI cabling (Options 21Ð81 IPE Module)
As shown in Figures 45 and 46, port 3 of the NT1R03AA cable connects to
SDI cards (except the NT8D41 SDI Paddle Board) through an NT8D82
cable, and if additional length is needed, through an NT1R03D cable. (See
Table 42 for lengths and specific codes.) For pinouts of the NT1R03AA,
NT8D82, and NT1R03D cables, refer to ÒExternal I/O cable pinoutsÓ in this
chapter. The NT6D80 MSDL card connects to the Meridian 1 I/O panel
using an NTND27 SCSI II cable. From the Meridian 1 I/O panel, an
NT7D58 cable connects to the IPE Module.
For more information about Option 11 SDI ports, refer to Option 11
Technical Reference GuideÑBook 1 (NTP 553-3011-100).
