Equipment cabling
The following tables provide checklists and references for checking the
cabling.
Input/output device cabling
Measure the cable distance for the input/output devices listed in Table 24.
For information on the proper cables and connections, refer to the
appropriate NTP.
Table 24
Input/Output devices cable distance
Input/Output devices NTP
IPE Module or Application
Module to Meridian 1
(Link cable) This guide
IPE Module or Application
Module to Meridian Mail
(Link cable) This guide
PBX to Meridian Mail
(Link cable) Options Installation Guide
(NTP 555-7011-210)
Options Maintenance Guide
(NTP 555-7011-500)
Meridian Mail Modular Option
Installation and Maintenance Guide
(NTP 555-7041-250)
Meridian Mail Modular Option GP
Installation and Maintenance Guide
(NTP 555-7051-250)
Meridian Mail Modular Option EC
Installation and Maintenance Guide
(NTP 555-7061-250)
Card Option Installation and
Maintenance Guide
(NTP 555-7071-210)
