Backplane cable rerouting for NT8D37 IPE Module
In the standard 12-cable configuration for the backplane in the NT8D37 IPE
Module, cables D, H, N, and U are not used. Those cables are used in the
16-cable fully expanded configuration.
Note: Backplane slots 0, 4, 8, and 12 (for cables A, E, K, and R) are
already fully cabled for 24 pairs, so no change is required for those
slots.
Table 67 lists cable connections before cable expansion. Figure 52 shows
the backplane slots before cable expansion.
Table 67
NT8D37 cable connections (standard configuration)
I/O panel connector
port
Backplane cable
connector
Backplane slot
position
A A-1 L0-1
A-2 L0-2
A-3 L0-3
B B-1 L1-1
B-2 L1-2
B-3 L2-1
C C-1 L2-2
C-2 L3-1
C-3 L3-2
E E-1 L4-1
E-2 L4-2
E-3 L4-3
F F-1 L5-1
F-2 L5-2
F-3 L6-1
ÑcontinuedÑ
