180 Chapter 9: Meridian Link/CCR interface cabling
553-3202-210 Standard October 1998
Table 56
Option 11 IPE ModuleÑNT1R03AA/NT1R03CA cable connections
(main cabinet)
Slots occupied by the
IPE Module
Connect NT1R03AA/NT1R03CA
cables to connector port
2, 3, 4 J4
3, 4, 5 J5
4, 5, 6 J6
5, 6, 7 J7
6, 7, 8 J8
7, 8, 9 J9
Table 57
Option 11 IPE ModuleÑNT1R03AA/NT1R03CA cable connections
(expansion cabinet)
Slots occupied by the
IPE Module
Connect NT1R03AA/NT1R03CA
cables to connector port
11, 12, 13 J13
12, 13, 14 J14
13, 14, 15 J15
14, 15, 16 J16
15, 16, 17 J17
16, 17, 18 J18
17, 18, 19 J19
18, 19, 20 J20
