Meridian America Link/Customer Controlled Routing User Manual
Page 218
200 Chapter 9: Meridian Link/CCR interface cabling
553-3202-210 Standard October 1998
Table 68
NT8D37 cable connections (fully expanded configuration)
I/O panel connector
port
Backplane cable
connector
Backplane slot
location
A
A-1
L0-1
A-2
L0-2
A-3
L0-3
B
B-1
L1-1
B-2
L1-2
B-3
L1-3
C
C-1
L2-1
C-2
L2-2
C-3
L2-3
D (new cable)
D-1
L3-1
D-2
L3-2
D-3
L3-3
E
E-1
L4-1
E-2
L4-2
E-3
L4-3
F
F-1
L5-1
F-2
L5-2
F-3
L5-3
G
G-1
L6-1
G-2
L6-2
G-3
L6-3
ÑcontinuedÑ
