152 Chapter 9: Meridian Link/CCR interface cabling
553-3202-210 Standard October 1998
Figure 42
NT1R03AA and NT1R03BA IPE Module cables
15-pin
Ethernet
Port 8
25-pin
25-pin
25-pin
25-pin
Port 2
Port 4
Port 6
NT1R03BA
Port 3
25-pin
25-pin
25-pin
25-pin
Port 7
Port 5
Port 1
NT1R03AA
