Chapter 12: Meridian 1 configuration for Meridian Link/CCR 315
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
Configure SDI port for conshare (X11 Release 17)
The SDI port is used for the optional console sharing feature, which allows
the IPE Module or the Application Module console to access Meridian 1
administration and maintenance programs. Port settings on the card should
reflect TTY mode at 2400 baud. Define the SDI port and its characteristics
by responding to the following prompts in LD 17.
Table 111
LD 17ÑConfigure SDI port (X11 Release 17)
Prompt Response Comment
REQ CHG Create or change information in the database
TYPE CFN Configuration record data block
PWD2
ISDN
PARM
CEQU
OVLY
IOTB Yes Change I/O terminals or devices
HIST
ADAN NEW TTY x Add SDI on port x (0Ð15) for console sharing
ESDI
USER MTC SCH Use this port for service change and
maintenance
VAS
VSID
DLOP
CMS
SECU
ATRN
ÑcontinuedÑ
