204 Chapter 9: Meridian Link/CCR interface cabling

553-3202-210 Standard October 1998

Table 69 lists cable connections for an IPE shelf with segment 0 rerouted.
Figure 54 shows the backplane slots in that IPE shelf.

Table 69
NT8D37 cable connections (segment 0 has been rerouted)

I/O panel connector

port

Backplane cable

connector

Backplane slot

position

A-1

L0-1

A-2

L0-2

A-3

L0-3

B-1

L1-1

B-2

L1-2

B-3

L2-1

D-1

L3-1

D-2

L3-2

D-3

L3-3

E-1

L4-1

E-2

L4-2

E-3

L4-3

F-1

L5-1

F-2

L5-2

F-3

L6-1

G-1

L6-2

G-2

L7-1

G-3

L7-2

K-1

L8-1

K-2

L8-2

K-3

L8-3

ÑcontinuedÑ
