Meridian America Link/Customer Controlled Routing User Manual
Page 319
Chapter 12: Meridian 1 configuration for Meridian Link/CCR 301
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
Table 106
LD 17ÑConfigure ESDI port (Options 21Ð81) (continued)
Prompt
Response
Comment
CMS
x
ESDI port number for this AML. This must
be the same as the port number defined at
the ADAN prompt.
SECU
YES
Security for AML. Must be set to Yes.
INTL
4
Time interval (five-second increments) used
to determine overload conditions
MCNT
400
Message count threshold for number of
messages per time interval (from INTL)
CONF
DIR
Direct link for this AML configuration
CMS
ESDI port number for CSL (0Ð15)
VSID
VAS
CSQI
(20)Ð255
Maximum call registers for AML input
queues
CSQO
(20)Ð255
Maximum call registers for AML output
queues
Set CSQI and CSQO equal to the number of
ACD agents or AST sets, or 50 whichever is
larger, but not more than 25 percent of the
total number of call registers (NCR prompt).
¥
¥
¥
Press [Return] until the REQ prompt
appears
REQ
END
Either change more configuration data or
exit the overlay, saving changes to the
configuration record.
Ñ end С
