308 Chapter 12: Meridian 1 configuration for Meridian Link/CCR
553-3202-210 Standard October 1998
Option 21Ð81 ESDI or MSDL configuration
Table 109
LD 17ÑConfigure ESDI or MSDL port (Options 21Ð81)
Prompt Response Comment
REQ CHG Create or change information in the
database
TYPE CFN Configuration record data block
ADAN NEW AML x Add AML on port x (VASID 0Ð15)
CTYP MSDL, ESDI Card type is MSDL or ESDI
DNUM 0Ð15 Device number; physical port for
AML on ESDI, physical card address
for MSDL
PORT 0Ð3 Port number on MSDL card (this
prompt only appears for MSDL)
DES aaa....a AML port designation (such as
ÒMeridian LinkÓ)
BPS 19200 19,200 bps baud rate (19.2 kbps).
The AML (connection from ESDI to
the IPE Module or the Application
Module) rate must match the baud
rate of link 0 on the IPE Module or
the Application Module.
PARM R232 DCE Interface and transmission mode
(MSDL port only)
CLOK INT Internal clock (this prompt only
appears for ESDI)
IADR 3 Individual address for the data-link
level HDLC protocol
ÐcontinuedÐ
