Chapter 9: Meridian Link/CCR interface cabling 183
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
Table 61
Option 11 IPE Module external connections (NT1R03BA cable)
NT1R03BA
port
External equipment External cable or reference
2 external modem NT1R03HF (for pinout, see
ÒExternal I/O cable pinouts.Ó
4 Meridian Mail Link See ÒMeridian Mail cabling
(IPE Module).Ó
6 X.25 Host Link NT1R03D or customer-supplied
cable. See Table 63 for pinout.
8 terminal/printer NT1R03D
Table 62
Console cable pinout (NT1R03D)
Meridian 1 Signal IPE Module
2 TXD 2
3 RXD 3
4 RTS 4
5 CTS 5
6 DSR 6
7 LRTN 7
8 DCD 8
20 DTR 20
1 GND 1
