526 Chapter 17: Hardware upgrade
553-3202-210 Standard October 1998
Procedure 29: Installing the MVME332XT or MVME332XTS
ACC card
1
Complete Procedure 3: Hardware powerdown.
2
Loosen the screws at the top and bottom of the card.
3
Use the ejectors to unlock the card.
4
Pull the card out of the Application Module.
5
Check the switches and jumpers on the replacement card (see
Tables 145 and 146).
6
Slide the replacement unit into the Application Module. Press hard in
the middle of the faceplate to seat the card.
7
Tighten the screws on the faceplate of the replacement card.
8
Restart power to the Application Module.
Table 145
MVME332XT ACC card switch settings
Switch
Position
1
2
3
4
5
6
7
8
S1
on
off
off
off
off
on
on
on
S2
off
off
on
on
Table 146
MVME332XT ACC card jumper settings
Block
Jumper setting
J1
1Р2, 5Р6, 7Р9, 8Р10, 11Р12, 15Р17
J4
1Р2
