186 Chapter 9: Meridian Link/CCR interface cabling
553-3202-210 Standard October 1998
has three 20-pin connectors (only 16 pins are used) labelled 1, 2, and 3, and
referred to as X-1, X-2, and X-3, in which X represents the I/O panel
connector port. For example, the backplane cable connected to I/O panel
connector port A has three connectors referred to as A-1, A-2, and A-3.
The location of the cable connectors on the backplane is designated by the
slot number (L0 through L9 for NT8D11, L0 through L15 for NT8D37) and
the shroud row (1, 2, 3). Using these designations, the slot positions in the
first slot are referred to as L0-1, L0-2, and L0-3.
!
CAUTION
Risk of equipment damage
Wear an antistatic wrist strap when handling components
to avoid equipment damage. The strap will also prevent a
shock due to electrostatic energy buildup.
