212 Chapter 9: Meridian Link/CCR interface cabling
553-3202-210 Standard October 1998
Table 70
Option 21 CE/PE cabinet connectors
Slots occupied by
the IPE Module
Connect
NT1R03AA to
connector port
Connect
NT1R03BA to
connector port
0Ð3
D
A
1Ð4
E
B
2Ð5
F
C
3Ð6
G
D
4Ð7
H
E
5Ð8
K
F
6Ð9
L
G
Table 71
Options 51Ð81 IPE cabinet connectors
Slots occupied by the
IPE Module
Connect
NT1R03AA to
connector port
Connect
NT1R03BA to
connector port
0Ð3
D
A
1Ð4
E
B
2Ð5
F
C
3Ð6
G
D
4Ð7
H
E
8Ð11
N
K
9Ð12
R
L
10Ð13
S
M
11Ð14
T
N
12Ð15
U
R
