Chapter 9: Meridian Link/CCR interface cabling 201
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
Table 68
NT8D37 cable connections (fully expanded configuration) (continued)
I/O panel connector
port
Backplane cable
connector
Backplane slot
location
H (new cable)
H-1
L7-1
H-2
L7-2
H-3
L7-3
K
K-1
L8-1
K-2
L8-2
K-3
L8-3
L
L--1
L9-1
L-2
L9-2
L-3
L9-3
M
M-1
L10-1
M-2
L10-2
M-3
L10-3
N (new cable)
N-1
L11-1
N-2
L11-2
N-3
L11-3
R
R-1
L12-1
R-2
L12-2
R-3
L12-3
S
S-1
L13-1
S-2
L13-2
S-3
L13-3
ÑcontinuedÑ
