Chapter 9: Meridian Link/CCR interface cabling 157
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
Table 44
NT1R03E cable pinouts (IPE Module)
Port pin
Signal
External
equipment pin
2
TD
2
3
RD
3
4
RTS
4
5
CTS
5
6
DSR
6
7
GND
7
8
CD
8
15
SCT
15
17
SCR
17
20
DTR
20
24
SCTE
24
