Chapter 11: Peripheral device cabling interface 283
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
Configuring the UDS 2440 modem for remote diagnostics
There are two ways to configure the UDS 2440 modem for remote
diagnostics: one procedure uses the modemÕs front panel buttons, while the
alternative procedure allows for configuration via a workstation. Both
procedures are outlined below.
The following procedure explains how to configure the UDS 2440 modem
via the front panel buttons on the modem.
1 Connect the modem to a power source next to the system.
2 Position the power switch on the rear panel of the modem to ON.
The LCD on the front panel will display the following: ####-## (for
example, 3050-5C, appears for two seconds).
3 Answer the prompts by pressing either the YES or the NO button on
the front of the modem panel. Each response will appear in the LCD
window. Table 103 lists the prompts and responses.
Note: If you press the wrong button, press the TALK/DATA button
followed by the NO button. This returns you to step 2.
