252 Chapter 9: Meridian Link/CCR interface cabling
553-3202-210 Standard October 1998
Table 88
Pinout of SDI Paddle Board J1 connector
Pin Number Signal Connector Port
1 CD1 J1 Port 1
2 RD1
3 TD1
4 DTR1
5 GND
6 DSR1
7 RTS1
8 CTS1
Table 89
Pinout of SDI Paddle Board J2 connector
Pin Number Signal Connector Port
1 CD2 J2 Port 2
2 RD2
3 TD2
4 DTR2
5 GND
6 DSR1
7 RTS2
8 CTS2
