Note: A connector housing surrounds the pins on the P1 and P2
connectors. Make sure you center the cable connector on the pins
within the housing.
¥
Plug the power harness into the connector on the MPDU (P3 if
the Application Module is installed next to the MPDU, P4 if the
Application Module is on the other side of the AEM).
Note: Make sure you connect all the cables securely.
Note: Return to Chapter 5, ÒHardware installation overviewÓ for
the
next procedure (Table 12).
