Procedure 3: Load application software from tape (continued)
1
Insert the tape (marked Tape 2 of 2) into the tape drive as shown in
Figure 119.
Ensure that the tape drive latch (if present) is fully closed after the
tape is inside. Once the tape is inserted correctly and the latch
completely closed, the tape active indicator light will come on briefly,
flicker a few times, then go out again.
Figure 119
Inserting cassette tape in tape drive
Notch
points down
Arrow
points in
This side in
Lock the tape drive latch
after tape is inserted
IPE Module drive
Application Module drive
Eject
button
Application tape
Tape 2 of 2
