536 Chapter 19: Single Terminal Access
553-3202-210 Standard October 1998
Figure 299
STA for Meridian Link/CCR on an Application Module
Mini SCSI
Port 0
MSDL
Mini SCSI
Port x
Female Connector
Male Connector
NTND27AB
NTND27AB
Meridian 1
I/O Panel
VT220
STA Terminal
NT7D61XX
NT7D79BA
SP1
MVME
712M
Generic
I/O Panel
Card 1
Conn 1
(x=1 or 2 or 3)
25-pin straight cable
Shielded
Connectors
Null Modem
25
DB
25
DB
9
DB
25
DB
Shielded
Connectors
