40 Chapter 4: Meridian Link/CCR hardware
553-3202-210 Standard October 1998
Figure 6 illustrates the IPE Module occupying slots 5Ð7 of the Option 11
main cabinet. Figure 7 illustrates the IPE Module occupying slots 14Ð16 of
the expansion cabinet.
Figure 6
Option 11 main cabinet
0 1 2 3 4 5 6 7 8 9
SCSI
Meridian Link
Meridian 1
Connector
panel
Pwr
Meridian Mail Power
supply
AC/DC Pwr
