Chapter 9: Meridian Link/CCR interface cabling 165
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
Table 52
NTND27AB cable pinout (IPE Module)
26-pin
connector
Signal
DB-25
connector
1
GND
1
2
TXD
2
3
RXD
3
4
RTS
4
5
CTS
5
6
DSR
6
7
LTRN
7
8
DCD
8
20
DTR
20
