228 Chapter 9: Meridian Link/CCR interface cabling

553-3202-210 Standard October 1998

If you are using an MVME712AM transition card, skip this step. To
connect an external modem to the Application Module, connect a
9-pin to 25-pin null modem cable from the Application Module
connector

J9 on the I/O subpanel

EXT MODEM on the universal I/O panel

card 1 conn 2 on the generic I/O panel

to the external modem.

Connect the modem to a central office (CO) line or 500/2500 line
card, and to a power source.

To connect the system console to the Application Module, connect a
9-pin-to-25-pin cable (or an extra NT7D61 cable) from the
Application Module connector

J7 on the I/O subpanel

SYS CONS on the universal I/O panel

card 1 conn 1 on the generic I/O panel

to the console. For more information, refer to ÒSystem console
cabling (Application Module)Ó in this chapter.

See Chapter 10, ÒInstalling peripheral devicesÓ in this guide for
information on configuring your terminal correctly. See Chapter 11,
ÒPeripheral device cabling interfaceÓ in this guide if you are using an
A/B switchbox with the system console.

To connect an SDI port to the Application Module for optional
conshare capability:

For SDI cards other than the NT8D41 SDI Paddle Board,
connect an NT7D61 cable from the Application Module
connector (J8 on the I/O subpanel, SDI LINK on the universal
I/O panel, or card 1 conn 3 on the generic I/O panel) to the SDI
port connector on the Meridian 1. For more information, refer to
ÒSDI cabling (Application Module)Ó in this chapter.

For an NT8D41 SDI Paddle Board, connect an NT7D46 cable
from the Application Module connector (J8 on the I/O subpanel,
SDI LINK on the universal I/O panel, or card 1 conn 3 on the
generic I/O panel) to the SDI port connector on the Meridian 1.
For more information, refer to ÒSDI Paddle Board cabling
(Application Module)Ó in this chapter.
