Chapter 12: Meridian 1 configuration for Meridian Link/CCR 295
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
Configuration overview
Install or upgrade the Meridian 1 to the appropriate software release (see
Chapter 2, ÒOverview of Meridian LinkÓ or Chapter 3, ÒOverview of
Customer Controlled RoutingÓ). To upgrade an existing system, refer to
Software Conversion Procedures (NTP 553-2001-320).
Summary of Meridian 1 configuration
1 Define the ESDI/MSDL, STA, and SDI ports in the Configuration
Record (LD 17).
Ensure that you refer to the prompts for your release of X11 software
(either Release 17 or later).
2 Identify VASID and define the status message groups in LD 15.
3 Define ACD groups and agents in Automatic Call Distribution
(LD 23) if required for the application.
4 Configure single-line telephones with the Associated Set (AST) and
Unsolicited Status Messages (USM) features in Single-Line
Telephone Administration (LD 10).
5 Configure multi-line telephones with the AST and USM features in
Multi-Line Telephone Administration (LD 11).
6 Configure Control DNs (CDNs) in LD 23 if required for Host
Enhanced Routing.
7 Enable the ESDI/MSDL port in Link Diagnostic (LD 48).
8 Enable the SDI port for console sharing in Input/Output Diagnostic
(LD 37).
