Chapter 9: Meridian Link/CCR interface cabling 225
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
Table 81
Cables to external equipment (Application Module) (continued)
Part number Length Cable description and application
NT7D61AB (A0374031)
NT7D61AD (A0374070)
NT7D61AF (A0374071)
NT7D61AL (A0374072)
NT7D61AT (A0374073)
NT7D61AV (A0374074) 0.6 m (2 ft.)
1.8 m (6 ft.)
3 m (10 ft.)
6 m (20 ft.)
10.6 m (35 ft.)
13.7 m (45 ft.) 25-pin round subminiature D-style cable: for an
SDI card, connects
¥ J8 on the I/O subpanel
¥ SDI link on the universal I/O panel
¥ card 1 conn 3 on the generic I/O panel
to the SDI port connection at the Meridian 1.
This cable may also be used
¥ to connect the modem port on the universal
I/O panel or card 1 conn 2 on the generic I/O
panel to the external modem
¥ with a gender changer, to connect the
system console to port J7 on the I/O
subpanel, the SYS CONS port on the
universal I/O panel, or card 1 conn 1 on the
generic I/O panel
NT7D71BA (A0394776)
(MVME712AM) 2.1 m (7 ft.)
(same length
revised) 9-pin subminiature D-style to 4-pin RJ11 cable
connects
¥ J9 on the I/O subpanel
¥ Int Modem on the universal I/O panel
to the MDF through in-house distribution (only
used with the MVME712AM card)
NT8D82AC
NT8D82AD 1.2 m (4 ft.)
1.8 m (6 ft.) 25-pin round subminiature D-style cable:
connects the ESDI card and SDI card (all types
except the NT8D41 SDI Paddle Board) to the
Meridian 1 I/O panel
NTND27AB 1.8 m (6 ft.) 26-pin SCSI II cable: connects the MSDL card
to the Meridian 1 I/O panel
Ñ continued С
