Meridian America Link/Customer Controlled Routing - Manual (Page 242)

224 Chapter 9: Meridian Link/CCR interface cabling
553-3202-210 Standard October 1998
Table 81
Cables to external equipment (Application Module)
Part number Length Cable description and application
NT7D46AB (A0373932)
NT7D46AD (A0373933)
NT7D46AF (A0373934)
NT7D46AL (A0373935)
NT7D46AT (A0373936)
NT7D46AV (A0373937) 0.6 m (2 ft.)
1.8 m (6 ft.)
3 m (10 ft.)
6 m (20 ft.)
10.6 m (35 ft.)
13.7 m (45 ft.) 9-pin round subminiature D-style cable: for an
SDI Paddle Board, connects
¥ J8 on the I/O subpanel
¥ SDI link on the universal I/O panel
¥ card 1 conn 3 on the generic I/O panel
to the SDI port connection at the Meridian 1
NT7D47EA 3 m (10 ft.) 15-pin drop cable: connects the Ethernet port
of the generic I/O panel to an Ethernet
transceiver (not shipped with the Application
Module)
NT7D58AB (A0373938)
NT7D58AD (A0373939)
NT7D58AF (A0373940)
NT7D58AL (A0373941)
NT7D58AT (A0373942)
NT7D58AV (A0373943 0.6 m (2 ft.)
1.8 m (6 ft.)
3 m (10 ft.)
6 m (20 ft.)
10.6 m (35 ft.)
13.7 m (45 ft.) 25-pin round subminiature D-style cable:
connects
¥ J2 on the I/O subpanel
¥ ESDI link on the universal I/O panel
¥ card 2 conn 1 on the generic I/O panel
to the ESDI/MSDL port connection at the
Meridian 1
NT7D61AB (A0374031)
NT7D61AD (A0374070)
NT7D61AF (A0374071)
NT7D61AL (A0374072)
NT7D61AT (A0374073)
NT7D61AV (A0374074) 0.6 m (2 ft.)
1.8 m (6 ft.)
3 m (10 ft.)
6 m (20 ft.)
10.6 m (35 ft.)
13.7 m (45 ft.) 25-pin round subminiature D-style cable: for an
SDI card, connects
¥ J8 on the I/O subpanel
¥ SDI link on the universal I/O panel
¥ card 1 conn 3 on the generic I/O panel
to the SDI port connection at the Meridian 1.
This cable may also be used
¥ to connect the modem port on the universal
I/O panel or card 1 conn 2 on the generic I/O
panel to the external modem
¥ with a gender changer, to connect the system
console to port J7 on the I/O subpanel, the
SYS CONS port on the universal I/O panel, or
card 1 conn 1 on the generic I/O panel
Ñ continued С
