130 Chapter 8: Hardware installation procedures
553-3202-210 Standard October 1998
If your Application Module does not have CCR activated, the
MVME332XT(S) card may not be present. If so, skip steps 1Ð3 and begin at
step 4.
1 Remove the screws at the top and bottom of the MVME332XT(S)
card faceplate.
2 Pull the MVME332XT(S) card out of the Application Module.
Check the switches as indicated in Tables 29 and 30.
Table 29
MVME332XT ACC card switch settings
Switch
Position
1 2 3 4 5 6 7 8
S1 on off off off off on on on
S2 off off on on
Table 30
MVME332XT ACC card jumper settings
Block Jumper setting
J1 1Р2, 5Р6, 7Р9, 8Р10, 11Р12, 15Р17
J4 1Ð2
3 Replace the MVME332XT(S) card and replace the screws at the top
and bottom of the faceplate.
4 Remove the screws at the top and bottom of the MVME333-2 XCC
card faceplate.
5 Pull the MVME333-2 XCC card out of the Application Module.
Check the switches as indicated in Table 31 and Figure 34.
