Chapter 9: Meridian Link/CCR interface cabling 193
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
Table 66 lists cable connections for a rerouted IPE shelf. Figure 51 shows
the backplane slots in a rerouted IPE shelf.
Table 66
NT8D11 cable connections (rerouted for slots 0Ð3)
I/O panel connector
port
Backplane cable
connector
Backplane slot
position
A
A-1
L0-1
A-2
L0-2
A-3
L0-3
B
B-1
L1-1
B-2
L1-2
B-3
L2-1
D
D-1
L3-1
D-2
L3-2
D-3
L3-3
E
E-1
L4-1
E-2
L4-2
E-3
L5-1
F
F-1
L5-2
F-2
L6-1
F-3
L6-2
H
H-1
L7-1
H-2
L7-2
H-3
L8-1
K
K-1
L8-2
K-2
L9-1
K-3
L9-2
Note: Connector ports C, G, and L are not used in this configuration.
