128 Chapter 8: Hardware installation procedures
553-3202-210 Standard October 1998
Figure 32
Disk/tape unit
M
V
M
E
1
4
7
or
1
6
7
M
V
M
E
3
3
3
-
2 M
V
M
E
3
3
2
X
T
S
Disk/tape unit: top Ð tape drive
bottom Ð hard disk drive
2 Slide the disk/tape unit into the slot at the far right of the Application
Module (facing the AEM).
Push the unit in hard and make sure the tabs at the top and bottom
of the unit lock into position. Tighten the two screws on the front of
the unit.
