122 Chapter 8: Hardware installation procedures
553-3202-210 Standard October 1998
3
Slowly slide the module along the slots into the shelf or cabinet,
making sure the latches at the top and bottom of the module are
unlatched. Press the faceplate to ensure that the module is firmly in
place. Make sure the latches at the top and bottom of the module
are secured.
4
For information on cabling the IPE Module to external equipment,
refer to the ÒMeridian Link/CCR cabling interfaceÓ chapter.
Note: Return to Chapter 5, ÒHardware installation overviewÓ for the
next procedure.
Figure 30 shows the port configuration settings on the CPU adapter card.
