168 Chapter 9: Meridian Link/CCR interface cabling
553-3202-210 Standard October 1998
Table 54
NTAK19BA cable pinout (IPE Module) (continued)
Meridian 1 Signal Port 2 pin
14 DSR2 6
15 RTS2 4
16 RXD2 3
38 DTR2 20
39 DCD2 8
40 CTS2 5
41 TXD2 2
42 SG2 7
Port 3 pin
17 SCTEA3 24
18 SCTEB3 23
19 DSR3 6
20 RTS3 4
21 SCRA3 17
22 SCRB3 12
23 RXDA3 3
24 RXDB3 16
43 DTR3 20
44 DCD3 8
45 CTS3 5
46 SCTA3 15
47 SCTB3 14
48 TXDA3 2
49 TXDB3 13
50 SG3 7
