Chapter 9: Meridian Link/CCR interface cabling 229
Meridian Link Release 5C/CCR Release 3C Installation and Upgrade Guide
5 To connect the MSDL port to the Meridian 1 I/O panel, connect an
NTND27 cable (if DCE) or an NTND26 (if DTE) cable from the MSDL
port to
¥ J2 on the I/O subpanel
¥ ESDI Link port on the universal I/O panel
¥ card 2 conn 1 on the generic I/O panel
6 To connect an ESDI/MSDL port to the Application Module, connect
an NT7D58 cable from the Application Module connector to
¥ J2 on the I/O subpanel
¥ ESDI LINK on the universal I/O panel
¥ card 2 conn 1 on the generic I/O panel
to the ESDI/MSDL port connection on the Meridian 1. For more
information, refer to ÒESDI/MSDL cabling (Application Module)Ó later
in this chapter.
7 To connect the Application Module to the Meridian Mail system:
¥ If your Application Module has an MVME712M transition card,
connect an NT7D58CA cable from SP4 of the MVME712M card
to card 1 conn 4 of the generic I/O panel, and connect an
NT7D58BB cable from card 1 conn 4 of the generic I/O panel to
the NT1R03 cable that connects to Meridian Mail. See Table 82
for pinouts of the NT7D58 cable.
¥ If your Application Module has an I/O subpanel, connect an
NT7D61DA cable from SP4 of the MVME712A or AM card to
port J1 of the I/O subpanel, and connect an NTND82AA cable
from port J1 to the NT1R03 cable that connects to Meridian Mail.
¥ If your Application Module has a universal I/O panel, connect an
NT7D61DA cable from SP4 of the MVME712A or AM card to the
spare port of the universal I/O panel, and connect an
NTND81AA cable from the spare port of the universal I/O panel
to the NT1R03 cable that connects to Meridian Mail.
For more information, refer to ÒMeridian Mail cabling (Application
Module)Ó later in this chapter.
